| Part NO. | Iout(Typ.) | Isw | Vin | Vout | Eff | Fsw & Mode | EXT | Enable | Typical Feature | Packages | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| CE8301A/C | 400mA | 0.8A | 0.9~6V | 1.8~6.0V | 85% | 100kHz@PFM | C:√ | Ultra Low Iss2=6μA | SOT89-3/5, SOT23-3/5, TO-92 |
|
|
| CE8301B/D | 1A | - | 0.9~6V | 1.8~6.0V | 85% | 100kHz@PFM | √ | D:√ | High Current | SOT89-3/5, SOT23-3/5, TO-92 |
|
| CE8303A/C | 500mA | 1A | 0.9~6V | 1.8~5.5V | 87% | 300kHz@PFM | C:√ | Low Output Noise | SOT89-3/5, SOT23-3/5, TO-92 |
|
|
| CE8303B/D | 2A | - | 0.9~6V | 1.8~5.5V | 87% | 300kHz@PFM | √ | D:√ | High Current | SOT89-3/5, SOT23-3/5, TO-92 |
|
| CE8401A/B | 300mA | 1A | 0.9~5V | 1.8~5.5V | 95% | 400kHz@PFM | B:√ | Sync, Low Iss2=6μA | SOT89-3, SOT23-3/5, SOT23, TO-92 |
|
|
| CE8400 | 500mA | 1.1A | 0.9~5.5V | 2.5~5.5V | 96% | 800KHz@PWM | √ | Sync. Rectifier | SOT23-6 |
|
|
| CE8406 | 500mA | 1.2A | 0.9~5.5V | 2.5~5.5V | 96% | 800KHz@PWM | √ | Sync, True Output Load Disconnect when Shutdown | SOT23-6 |
|
|
| CE8405 | 500mA | 1A | 0.9~5V | 2.2~5.5V | 96% | 500KHz@PWM/PFM | √ | Sync, Low Iq True Output Load Disconnect when Shutdown | SOT23-6 |
|
|
| CE8407 | 100mA | 0.4A | 0.8~5V | 1.8~5.5V | 96% | PFM | √ | Sync, Rectifierz | SOT23-6, SC70-6 |
|
|
| CE9908A/B | 1A | - | 0.9~6V | Adj. | 85% | 100kHz@PFM | √ | B:√ | Adjustable Output | SOT23-5，SOT89-5 |
|
